A – Cannula housing:
a plastic housing with a soft cannula or steel needle that is attached to the skin by an adhesive tape
B – Soft cannula or steel needle:
a small soft cannula or steel needle that is inserted into the subcutaneous skin layer and that allows the insulin to flow into the body
C – Tubing:
a plastic tube that allows insulin to flow from the insulin pump to the body
D – Site connector:
a connector that clicks into the cannula housing and connects the plastic tubing to the infusion site. It allows for temporary disconnection of the pump.**
E – Pump connector:
a connecting lock that connects the plastic tubing to the insulin pump
inset™
- Insertion via integrated insertion device
- 90° insertion angle
- Soft cannula
- Disconnect at insertion site
- Available with 6 and 9 mm cannula length
- Available with 12, 60, 80 and 110 cm (5, 23, 32 and 43 inch) tubing length
Supplied to our partners under the brand names*:
- Tandem: AutoSoft™ XC
- Beta Bionics: inset™
*To ensure compatibility between infusion set and insulin pump, the listed infusion sets need to be used together with the intended pump supplied by the pump manufacturer.
inset™ II
- Insertion via integrated insertion device
- 90° insertion angle
- Soft cannula
- Disconnect at insertion site
- Available with 6 and 9 mm cannula length
- Available with 60 and 110 cm (23 and 43 inch) tubing length
Supplied to our partners under the brand names*:
- Medtronic: MiniMed™ Mio™
- Tandem: AutoSoft™ 90
- Ypsomed: YpsoPump® Inset
- SOOIL: Dana inset™ II
*To ensure compatibility between infusion set and insulin pump, the listed infusion sets need to be used together with the intended pump supplied by the pump manufacturer.
inset™ 30
- Insertion via integrated insertion device
- 30° insertion angle
- Soft cannula
- Disconnect at insertion site
- Available with 13 mm cannula length
- Available with 60 and 110 cm (23 and 43 inch) tubing length
Supplied to our partners under the brand names*:
- Medtronic: MiniMed™ Mio™ 30
- Tandem: AutoSoft™ 30
*To ensure compatibility between infusion set and insulin pump, the listed infusion sets need to be used together with the intended pump supplied by the pump manufacturer.
inset™ guard
- Insertion via integrated insertion device
- 90° insertion angle
- Soft cannula
- Disconnect at insertion site
- Available with 6 and 9 mm cannula length
- Available with 46, 60, 80 and 110 cm (18, 23, 32 and 43 inch) tubing length
Supplied to our partners under the brand names*:
- Medtronic: MiniMed™ Mio™ Advance
*To ensure compatibility between infusion set and insulin pump, the listed infusion sets need to be used together with the intended pump supplied by the pump manufacturer.
contact™ detach
- Manual insertion
- 90° insertion angle
- Stainless steel cannula
- Disconnect at separate site
- Available with 6 and 8 mm cannula length
- Available with 60 and 80 cm (23 and 32 inch) tubing length
Supplied to our partners under the brand names*:
- Medtronic: MiniMed™ Sure T™
- Tandem: TruSteel™
- Beta Bionics: contact™ detach
*To ensure compatibility between infusion set and insulin pump, the listed infusion sets need to be used together with the intended pump supplied by the pump manufacturer.
comfort™/comfort™ short
- Manual insertion
- 20-45° variable angle insertion
- Soft cannula
- Disconnect at insertion site
- Available with 13 and 17 mm cannula length
- Available with 60, 80 and 110 cm (23, 32, and 43 inch) tubing length
Supplied to our partners under the brand names*:
- Medtronic: MiniMed™ Silhouette™
- Tandem: VariSoft™
*To ensure compatibility between infusion set and insulin pump, the listed infusion sets need to be used together with the intended pump supplied by the pump manufacturer.
